TPO (Thermoplastic Polyolefin)

Thermoplastic Olefin (TPO) refers to a mixed material composed of polyolefin (PP or PE), rubber, and certain fillers (talc, carbon, fiber). These are members of the TPE (Thermoplastic Elastomers) family.

They generally have good hardness, flexural fatigue, impact resistance, and excellent resistance to certain chemicals. TPO is also highly resistant to UV radiation and extremes in temperature, making it ideal for outdoor use. TPO Sheets are often used in both injection molding and thermoforming projects.

Waterproofing concrete with roof reinforcement is an important task on concrete structures for roof repair and preservation. Many roofs throughout the world are constructed using poured concrete. These structures are usually made with reinforced steel. They are inexpensive but require a great deal of maintenance to keep them from leaking since they shift, move, and dissolve easily. Concrete is made up from several ingredients including calcium carbonate and sand. Calcium Carbonate is a plentiful substance that comes from the dead skeletons of sea life. These plentiful substances dissolve quite easily in very wet environments unless they are protected.

Unprotected concrete cracks and dissolves in many areas where there are heavy rains. During winter, water leaks into the unprotected cracks and freezes which expand substantially further damaging your concrete building. Mandhana Polymers Pvt Ltd. Company specializes in the making of specialty plastic TPO sheet that extend the life of these concrete roofs. These TPO sheets Prevent water from seeping by forming a waterproof membrane.

Mandhana sheets are made to take care of your roof waterproofing requirements in any weather conditions. Also enlisted are the features of Mandhana sheets that clearly state the advantages over the existing methods of water proofing procedures which have a limited life period.

  • • High Mechanical resistance
  • • Resistance to the action of running water
  • • Resistance to root penetration
  • • Flexibility at low temperature
  • • Resistance to common parasites
  • • Resistant to bursting

  • • Waterproofing of foundations
  • • Foundation and damp screen
  • • Damp Screen for cellars and vertical walls
  • • Natural and artificial tunnels
  • • Flag vacuum systems

  • • Thickness: 1 - 1.5 – 2 mm
  • • Width: 1.25 / 1.5 mtr
  • • Length: any as per requirement
  • • Colour: any as per requirement

  • • Totally independent installation according to the selected strategraphy.
  • • Edges overlapped and joined by means of : Automatic Welding machine, Hot air welding machine in a dry environment.

FEATURES TPO
Expected life > 30 years
High chem. Compatibility YES
Hot air welding YES
Singal Layer YES
Elongation > 500%
Tensile Strength > 15 Mpa
Puncture Resistance HIGH
Density 0,92 Kg/m2
Colour Any
Reinforcement YES
Fleece backed (if demanded) YES
Shrinkage (if not reinforced) NO
Sensitive to extreme hot/cold NO
Expected life proportional to the thickness NO
Vapour Permeability NO
Full Range Accessories YES
Hot Air Welding YES
Solvent Welding NO

Features TPO Waterproofing Chemicals Tile Chips
Expected Life 35 years >5 years >5 years
Surface Preparation Just sweeping of debries and other removable items. Power washing of the surface area of the roof to remove most of the loose material. Use caution, so as not to damage any interior areas due to roof leakage that are inside the building. You may need to roughen the Surface. Any large cracks and crevices needs to be filled with cement and other materials. Power washing of the surface area of the roof to remove most of the loose material. Use caution, so as not to damage any interior areas due to roof leakage that are inside the building. You may need to roughen the Surface. Fill any large cracks and services.
Primer Not Required Primer needs to be applied before final coat is applied. Primer needs to be applied before final coat is applied.
Time for erecting of 100 Sq Mtr. 4-5 Hours 3-4 days depending on climatic conditions. 5-6 days depending upon climatic conditions.
Aesthetics Naturally looks clean. Depends upon the workmanship of the labour. Depends upon the workmanship of the labour.
Testing Testing can be done at site immediately after erection. Have to wait for sufficient period for the surface to get dry and no specific recommended foolproof test procedure. Have to wait for sufficient period for the surface to get dry and no specific recommended foolproof test procedure.
Cost Economical as compare to conventional methods. Rs 125 – Rs 150 per Sq Ft. approximate. Depending upon surface conditions. Pluslabour charges. Rs 125-Rs 150 per Sq Ft. approximate. Depending upon surface conditions. Pluslabour charges.
Climatic condition sustainability. All extreme climate Grade of materials vary as per climatic conditions Grade of materials vary as per climatic conditions
Erecting Can be erected in all weather conditions. Cannot be installed during wet atmosphere Cannot be installed during wet atmosphere

    • Density - 0.88
      Unit - gm/cm³
      Standard - ISO 1183

    • Tensile Strength at Yield (óS) - 20
      Unit - Mpa
      Standard - ISO 527-1, -2

    • Tensile Stress at Break - 6
      Unit - Mpa
      Standard - ISO 527-1, -2

    • Flexural Modulus - 80
      Unit - Mpa
      Standard - ISO 178

    • Vicat Softening Point - 60
      Unit - (degree)C
      Standard - ISO 306

    • Izod Impact Strength (Notched) - No Break
      Unit -
      Standard - ISO 180
